    11.6" Embedded Touch Panel PC Full HD 1920x1080 PCAP Project Capacitive Touch

    Ask Lasest Price
    Brand Name : Shinho
    Model Number : SC116
    Certification : CE , FCC , RoHS
    Price : Negotiable
    Payment Terms : T/T, Paypal, L/C, D/A , D/P, Western Union, MoneyGram
    Supply Ability :
    Delivery Time :
    • Product Details
    • Company Profile

    11.6" Embedded Touch Panel PC Full HD 1920x1080 PCAP Project Capacitive Touch

    11.6" Embedded Touch Panel PC Full HD 1920x1080 PCAP Project Capacitive Touch


    Features

    • 11.6" industrial LCD panel
    • CPU Intel Celeron J1900, Quad core, 2.0GHz, fanless
    • 2GB DDR3, 32GB SSD (can upgrade as your requirement)
    • Full HD 1920*1080 widescreen, 16:9
    • PCAP project capacitive touch, or no touch
    • Front panel waterproof IP65
    • 3MM thin bezel, perfect for embedded mounting
    • Whole body aluminum alloy, excellent thermal dissipation

    Specification

    Model:SC116

    PC

    CPU

    Intel® Celeron J1900, quad core, 2.0GHz, fanless

    Chipset

    Intel ValleyView SSA-CUnit

    Memory

    2GB DDR3 (4G, 8G optional)

    Hard Drive Capacity

    32GB SSD

    Hard Drive Optional

    SSD: 64G, 128GB, 256GB

    HDD: 500GB, 1TB

    Graphics

    CPU Integrated graphics HD Graphics and support 1080p HD photo quality

    Audio

    Realtek ALC662, High Definition Audio (HD), Line in, Line out

    Network

    1xRealtek RTL 8111E Gigabit Ethernet controller

    Wireless Network

    WIFI

    I/O Interface

    2xUSB, 1xCOM RS232

    1xVGA/HDMI/RJ45/Audio OUT/MIC IN/POWER DC

    Operation System

    Support Windows 7/8/10, Linux, Ubuntu, Debian, etc.

    LCD panel

    Panel size

    11.6"

    Resolution

    1920*1080 Full HD

    Aspect ratio

    16:9

    Support Color

    16.7M colors

    Brightness (cd/m²)

    300+

    Response time

    5ms

    Contrast ratio

    1000:1

    View angle

    80°/80°/80°/80° (R/L/U/D)

    Touch panel

    Touchscreen Type

    Project Capacitive Touch (10 points)

    Touch Interface

    USB (RS232 optional)

    Touch response time

    2ms

    Luminousness

    90%

    Surface Hardness

    7H

    Working life

    >50 million times

    Touch options

    (5 wire resistive touch, IR touch optional)

    Power Supply

    External Power Supply

    AC 100-240V

    Working voltage

    DC 12V

    Power consumption

    ≤45W

    Enclosure

    Material

    Aluminum Alloy

    Color

    Silver, Black, white, color can be customized

    VESA mounting

    75x75mm/100x100mm

    IP grade

    Front panel IP65 waterproof

    Operating Environment

    Temperature Range

    operating: -10 to 60°C, storage: -20 to 80°C

    Relative humidity

    5%~95% @ 40° C, non-condensing

    Vibration

    5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis

    Packing Details

    Net weight

    3.5kg

    Gross weight

    4kg

    Product Dimension

    32.37x21.85x5.15cm

    Packing size

    43x38x19cm

    Accessories

    Power adapter, embedded screws, user manual, warranty card

    Other

    Mounting (options)

    embedded mounting screws

    wall mounting brackets (optional)

    desk stand holder (optional)

    Warranty

    1 year warranty

    Certificate

    CE, FCC, RoHS


    Applications
    Parking system

    Packaging inspection equipment

    Self payment machine
    Traffic control system

    Industrial control equipment

    Voting machine

    Vending machine

    Access control system
